Package content
8x Hikvision DS-2CD2386G2-IU Turret Camera 2.8mm Black
1x DS-7608NXI-K1/8P
1x Hard Disk 6Tb for surveillance
8x Patch Cable CAT6 20m Black



The EasyIP 4.0 AcuSense camera from Hikvision is a low light camera with a resolution of 8MP. By default, this camera has 120dB WDR and H265+.
Cameras from the EasyIP4.0 series are Powered by Darkfighter. This means that a combination of a light-sensitive sensor and the DarkFighter image optimization technology ensures that the camera can provide color images in low-light situations. This series of cameras is distinguished by the unique AcuSense technology. This is an advanced algorithm that is able to recognize vehicles and people, allowing a very accurate detection

Kit Contents:

2x HIKVISION Bullet Camera DS-2CD1083G2-LIUF (2.8mm)
8MP POE 2.8mm Indoor / Outdoor - Audio Built-In
Smart Hybrid G2 Motion Detection Camera
1x NVR 4 Channel POE: DS-7604NI-K1/4P
1x 2TB HDD Special Surveillance
2x Patch Cable 20m Cat6
Expandable to 4x Cameras

Kit Contents:

4x HIKVISION Bullet Camera DS-2CD1083G2-LIUF (2.8mm)
8MP POE 2.8mm Indoor / Outdoor - Audio Built-In
Smart Hybrid G2 Motion Detection Camera
1x NVR 8 Channel POE: DS-7608NI-K1/8P
1x 2TB HDD Special Surveillance
4x Patch Cable 20m Cat6
Expandable to 8x Cameras

Kit Contents:

6x HIKVISION Bullet Camera DS-2CD1083G2-LIUF (2.8mm)
8MP POE 2.8mm Indoor / Outdoor - Audio Built-In
Smart Hybrid G2 Motion Detection Camera
1x NVR 8 Channel POE: DS-7608NI-K1/8P
1x 4TB HDD Special Surveillance
6x Patch Cable 20m Cat6
Expandable to 8x Cameras

Kit Contents:

8x HIKVISION Bullet Camera DS-2CD1083G2-LIUF (2.8mm)
8MP POE 2.8mm Indoor / Outdoor - Audio Built-In
Smart Hybrid G2 Motion Detection Camera
1x NVR 8 Channel POE: DS-7608NI-K1/8P
1x 4TB HDD Special Surveillance
8x Patch Cable 20m Cat6

KIT HIKVISION HDTVI 4x Cameras 5 Mpx
1 x DVR HD-TVI DVR DS-7204HTHI-K1
4x DS-2CE76H0T-ITMFS Audio Turret 5 Mp - 2.8mm
1x Hard Disk 1TB Special Surveillance Preinstalled
4x Coax Hybrid 20m
PSU 12V-5A + Splitter 4X
1 Cat.6 3m Patch Cable

Series Overview
With features of simple installation, easy operation, and high
performance-cost ratio, Dahua Entry series network camera is
applicable to small and medium-sized scenes, such as homes/
residences, small-sized retail stores, and other small and mediumsized enterprises.

Functions
Smart Dual Light
Dahua Smart Dual Light technology adopts smart algorithm to detect
targets. Usually, the IR illuminator is on at night; when the target
appears in the monitoring area, the white light is on, and the camera
records the full-color video and information of key events. That is,
the camera links snapshot and video with full-color image. When the
target is out of the monitoring area, the white light is off and the IR
illuminator is on, which reduces light pollution efficiently.
Human Detection
Dahua intelligent algorithms extract moving human targets from
videos and filters out alarms that are triggered by non-human targets
to increase the accuracy and effectiveness of alarms.
Smart H.265+ & Smart H.264+
With advanced scene-adaptive rate control algorithm, Dahua smart
encoding technology realizes the higher encoding efficiency than
H.265 and H.264, provides high-quality video, and reduces the cost
of storage and transmission.

Image Flip
For narrow and long scenes, Dahua image flip technology flips the
image by 90°/180°/270° to realize better surveillance in rotation mode

This Set contains:

1x NVR 4x POE channels: DS-7604NXI-K1/4P
2x Camera Turret Acusense 8MP DS-2CD2383G2-IU (2.8mm)
Audio Built In - Indoor/Outdoor
2TB hard drive pre-installed
2 RJ45 cat.6 F/UTP cables 20 meters
Expandable to 4 camera

DS-2CD2363G2-I(U) - 2.8mm
6 MP AcuSense Fixed Turret Network Camera
High quality imaging with 6 MP resolution
Efficient H.265+ compression technology
Clear imaging against strong backlight due to 120 dB WDR technology
Focusing on human and vehicle classification based on deep learning
Built-in microphone for real-time audio security
Water and dust resistant (IP67)

ColorVu IP67 Indoor/Outdoor

IR Dist: 30m Normal IP67 Indoor/Outdoor

· 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition
· Outputs max. 8MP (3840 × 2160) @20 fps (AI function enabled by
default) and supports 8MP (3840 × 2160) @25/30 fps (when AI function
disabled)
· H.265 codec, high compression rate, low bit rate
· Built-in IR LED, max. IR distance: 30 m
· ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments.
· Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking,
applicable to various monitoring scenes
· Intelligent detection: Intrusion, tripwire (support the classification and
accurate detection of vehicle and human)
· Abnormality detection: Motion detection, video tampering, scene
changing, audio detection, no SD card, SD card full, SD card error,
network disconnection, IP conflict, illegal access, and voltage detection
· Supports max. 256 G Micro SD card, built-in Mic
· 12V DC/PoE power supply
· IP67 protection
· SMD Plus

· 5MP, 1/2.7" CMOS image sensor, low illuminance, high image definition
· Outputs max. 5MP (2592 × 1944) @25/30 fps
· H.265 codec, high compression rate, ultra-low bit rate
· Built-in efficient IR illuminator, and the max. illumination distance: 10 m
· ROI, SMART H.264+/H.265+, flexible coding, applicable to various
bandwidth and storage environments
· 120dB WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to
various monitoring scenes
· Intelligent detection: Intrusion, tripwire, people counting in area
· Abnormality detection: Motion detection, video tampering, scene
changing, audio detection, no SD card, SD card full, SD card error,
network disconnection, IP conflict, illegal access, and voltage detection
· Alarm: 1 in, 1 out; audio: 1 in, 1 out; supports max. 256 G Micro SD
card, built-in Mic
· 12V DC/PoE power supply, easy for installation
· Heat map for people counting. You can adjust the number of people,
time threshold to generate a heat map, which can be exported.

KIT HIKVISION HDTVI 8x Cameras 5 Mpx :
1 x DVR HD-TVI DVR DS-7208HUHI-K1/E
1x Hard Disk 2TB Special Surveillance Preinstalled
8x HD-TVI DS-2CE17H0T-IT1 5MP Dome Camera Fixed Lens 2.8mm
8x Coax Hybrid 20m
PSU 12V-10A + Splitter 8X
1 Cat.6 5m Patch Cable

KIT HIKVISION HDTVI 6x Cameras 5 Mpx :
1 x DVR HD-TVI DVR DS-7208HUHI-K1/E
1x Hard Disk 2TB Special Surveillance Preinstalled
6x HD-TVI DS-2CE17H0T-IT1 5MP Dome Camera Fixed Lens 2.8mm
6x Coax Hybrid 20m
PSU 12V-10A + Splitter 8X
1 Cat.6 5m Patch Cable
